HH ELECTRONICS M-750D 2U 750W Power Amplifier
M-750D M-Series Power Amplifiers
HH M-Series power amplifiers are high power, 2U rack amplifers designed to provide maximum performance for demanding applications . Three models are available all featuring heavy duty low noise toroidal power supplies and rugged construction. Suitable for anywhere you need high fidelity, high power amplification
Featuring high quality balanced XLR inputs, user selectable input sensitivity , SpeakON(®) Connectors, binding post outputs, status indicators, Twin volume controls and comprehensive protection circuits.
HH has over five decades of experience designing quality power amplifiers, and indeed was one of the pioneers in this area.
-
Amplifier Type - Class H High Performance Professional linear design
-
Controls - Volume Controls (per channel), Power switch, Input Sensitivity Switch, Bridge/Routing Mode Switch
-
Dimensions - 88 x 482 x 239mm, 3.5 x 19 x 9.4"
-
Features - Soft start, comprehensive protection
-
Inputs - 2x Balanced XLRs
-
Outputs - 2x locking SpeakON® connectors, 4x 4mm binding posts (with safety cover), 2x Balanced XLR link outs
-
Output Power : 4 Ohm Stereo 2x750W
-
Output Power : 8 Ohm Stereo 2x500W
-
Output Power : 8 Ohm Bridge 1500W
-
System Type - 2U Professional Power Amplifier
-
Weight - 12.5Kg/pc, 27.6 lbs/pc
-
Cooling - Forced air, variable speed fan, air flow front to back
-
Damping Factor - >200
-
Input Sensitivity - 0.775V/1.4V
-
Packed Weight - 14.8Kg/pc, 32.6 lbs/pc
-
Protection - Soft start, VHF, RF, short circuit, over load, clip limit, over heat
-
S/N - ≥100dB
-
Voltage Gain (8Ω) - 36dB
-
Input Impedance (Bal/Unbal) - 20KΩ/10KΩ
-
Frequency Response - 20Hz - 20KHz (+0, -1dB)
-
Slew Rate - ≥20V/µS
-
THD+N - ≤0.5% 20Hz-20kHz
-
Power Connector - Removeable IEC Power Cord C14
-
Carton Dimensions (Hwd) - 160 x 580 x 540mm, 6.3 x 22.8 x 21.3"
Availability (Please click here for availability info):
GET FREE SHIPPING AUSTRALIA WIDE ON THIS PRODUCT!
GET FREE AUSTRALIA POST SHIPPING INCLUDED ON THIS ITEM - FIND OUT MORE
M-750D M-Series Power Amplifiers
HH M-Series power amplifiers are high power, 2U rack amplifers designed to provide maximum performance for demanding applications . Three models are available all featuring heavy duty low noise toroidal power supplies and rugged construction. Suitable for anywhere you need high fidelity, high power amplification
Featuring high quality balanced XLR inputs, user selectable input sensitivity , SpeakON(®) Connectors, binding post outputs, status indicators, Twin volume controls and comprehensive protection circuits.
HH has over five decades of experience designing quality power amplifiers, and indeed was one of the pioneers in this area.
-
Amplifier Type - Class H High Performance Professional linear design
-
Controls - Volume Controls (per channel), Power switch, Input Sensitivity Switch, Bridge/Routing Mode Switch
-
Dimensions - 88 x 482 x 239mm, 3.5 x 19 x 9.4"
-
Features - Soft start, comprehensive protection
-
Inputs - 2x Balanced XLRs
-
Outputs - 2x locking SpeakON® connectors, 4x 4mm binding posts (with safety cover), 2x Balanced XLR link outs
-
Output Power : 4 Ohm Stereo 2x750W
-
Output Power : 8 Ohm Stereo 2x500W
-
Output Power : 8 Ohm Bridge 1500W
-
System Type - 2U Professional Power Amplifier
-
Weight - 12.5Kg/pc, 27.6 lbs/pc
-
Cooling - Forced air, variable speed fan, air flow front to back
-
Damping Factor - >200
-
Input Sensitivity - 0.775V/1.4V
-
Packed Weight - 14.8Kg/pc, 32.6 lbs/pc
-
Protection - Soft start, VHF, RF, short circuit, over load, clip limit, over heat
-
S/N - ≥100dB
-
Voltage Gain (8Ω) - 36dB
-
Input Impedance (Bal/Unbal) - 20KΩ/10KΩ
-
Frequency Response - 20Hz - 20KHz (+0, -1dB)
-
Slew Rate - ≥20V/µS
-
THD+N - ≤0.5% 20Hz-20kHz
-
Power Connector - Removeable IEC Power Cord C14
-
Carton Dimensions (Hwd) - 160 x 580 x 540mm, 6.3 x 22.8 x 21.3"
